Blink Plus - 22W- 5.5'' x 24'' Surface Mount LED - 4000K - White Finish - 120-277V : A0C7E

No Image
Available

Image may not reflect selected features

Blink Plus - 22W- 5.5'' x 24'' Surface Mount LED - 4000K - White Finish - 120-277V (A0C7E) by Nuvo 62/1255

22W; 5.5 in.; x 24 in.; Surface Mount LED Fixture; 4000K; 90 CRI; Low Profile; White Finish; 120/277V

Product Specification

Item #

A0C7E

Dimensions

Height: 0.75"

Width: 5.50"

Additional product details

Vendor Item #

62/1255

Internal #

A0C7E

Category

Close-to-Ceiling

Sub Category

Edge Lit

Style

Utility

Avg Rated Hours

50000

Bulb Shape1

Integrated LED

Bulb Type1

LED

Color Temperature

Cool White

Dimmable

Yes-Dimmable

Each Height

8.27

Each Length

25.2

Each Width

2.48

Length

Lumens

1870L

Tariff Code

9405.11.8020

Warranty

5 Year Limited - Fixtures

Amps

0.183/0.079A

ANSI Base

Integrated

BAA Compliant

CA Prop-65

Lead

CCT Selectable

CEC

California T24 2016 - 2022 JA8 Listed

CEC Terse

Lawful for sale in California

CEC Web Text

California T24 Listed

Closet Rated

Yes

Connection

Direct Wired

Country Of Origin

China

CRI

Dimmable Down To

100 to 10 percent

Dimmable Function

120V only

Dimming Type

Reverse Phase or Phase Selectable

Each Cube

0.2991

Each Quantity

Efficacy

85.00 LPW

ES Category

Ceiling Mount

ES Unique ID

ESID-2291241

FCC Compliant

Yes

Feature 1

Length: 24.00 inches, Width: 5.50 inches, Height: 0.75 inches

Feature 2

White Finish

Feature 3

5 year limited warranty

Feature 4

1870 lumens

Feature 5

Dimmable

Feature 6

4000K Cool White Light

Feature 7

Superior 90 CRI light quality

Feature 8

Rated for 50,000 hours

Feature 9

FCC and RoHS compliant

Finish Family

White

Fixture shape

Linear

Incandescent Equivalent

100W

Indoor Outdoor

Indoor

JA8 Compliant

Yes

Long Description

Satco's 62-1255 22 watt, 24 inch by 5 inch surface mount LED fixture is an easy to install lighting solution for residential and commercial applications. Illuminate kitchens, bathrooms, hospitals, offices, and retails spaces with this dimmable, LED sur

Material

Aluminum

Mounting Procedure

Ceiling

NEC Compliance

Clothes Closet Certified - Reg: 410.16 (A)(3) and 410.16 (C)(5)

Operating Frequency

50/60Hz

Operating Temp

-17C (+1.4F) to +45C (+113F)

Pack Type

Box

Power Factor

0.8

Quantity In Pack

Replaceable Light Source

RoHS Compliant

Yes

Romance Copy

Satco's 22 watt, 24 inch by 5 inch surface mount LED fixture is an easy to install lighting solution for residential and commercial applications. Illuminate kitchens, bathrooms, hospitals, offices, and retails spaces with this dimmable, LED surface mou

Safety Listing

cETLus - Listed

SDS class

LED_Fixture

Short Description

22W/LED/5"X24"/FLUSH/4K/WH

Temperature (CCT)

4000K

Title 20 Compliant

Title 24 Compliant

Yes

Wattage Selectable

Weight Lb.

2.82

Manufactured By

Nuvo

Finish

Additional options that would change other selections
